IKUSI MT0512 5-Wire Distribution System 4x SAT / 1x TER Multi-switches with 12 Outlets

IKUSI 521065: MT-0512: Multi-switch 5 Input / 12 Output, Foxtel Approved.

• Low cost high performance, proven technology for SMATV distribution
• Stand alone Multiswitches for 5-wire system.
• Distribution of 4 satellite – IF polarizations and 1 terrestrial signal to 12 users of satellite systems
• Active satellite & terrestrial with continuous gain adjustments.
• Satellite path supplied from user receivers. IF polarization switching by voltage/tone.
• Terrestrial path supplied from separate DC input or from power on the SAT 1H or 2H inputs with LEDindicator.
• Sheet metal housing, indoor mounting, wall fixing.
• Foxtel Approved

MT-0512

Suitable to replace Hills Commercial Series 5-Wire 16 Way Multi-Switches

Available downloads for this item:

Click to view - Product DATA Sheet
