Kingray MHV25F Series VHF Only 25Db Gain Masthead Amplifier with NonShielded Housing

Kingray Logo

$70.40 Inc. GST

SKU: MHV25F Category: Tag: Brand:
Description

Kingray MHV Series MHV25F VHF Only 25Db Gain Masthead Amplifier with NonShielded Housing

The MHV25F is a VHF TV masthead amplifier, specifically designed to work in areas where there is VHF transmission only. With band 1, 2, 4 and 5 filtering, it ensures ensure only channels 6 to 12 (174 MHz to 230 MHz) are amplified, eliminating all unwanted frequencies including those in the 4G/LTE band.

  • Frequency Range 174-230 MHz
  • 25dB Maximum Gain
  • 10dB Gain Control
  • Single VHF Input
  • Weatherproof Housing
  • High Output Figure of 105dB IMR3 (DIN45004B)
  • Connectors: F-Type
  • Power Consumption: 60mA
  • Suitable Power Supply: PSK06 Series or PSK08 Series



Weight 0.6 kg
Dimensions 14 × 12 × 5 cm

Available downloads for this item:

Click to view - Product DATA Sheet - Standard 5-Wire Amplifier
