TRIAX 492787 TDcH 16S-I/ProI with Pro:Idiom (LG) 16xSAT to DVB-T/C Compact Headend + 8xCI

TRIAX Compact Series TDcH-16S-I/ProI 492787 with Pro:Idiom (LG) Included.  DVB-S/S2 conversion to QAM or DVB-T COFDM (switchable) with the possibility to decrypt services centrally in the headend.
Built for both wall mounting and 19” racks and equipped with 4 DVB-S/S2 inputs, 16 DVB-S2X tuners, 16 QAM or COFDM (switchable) modulators and 8 CI slots.
The TDcH compact headend is optimised and engineered to meet specific TV distribution requirements in hospitality, multi-dwelling units and related sectors with an appealing, competitive cost per service ratio.
Our brand new, intuitive platform smoothly integrates easy installation, an elegant graphical user interface, central decryption, remote access, and straightforward TV service updates with LCN.

Pro:Idiom (LG) Included

• Encrypts the signals sent to LG hospitality TVs, safeguarding against the unauthorized reproduction of copyright content from TV channels
• Scrambling up to 24 services for LG Hospitality TVs
• Protection of the premium contents

Features

• 4 x SAT IF inputs with integrated multiswitch
• 16 x DVB-S2 tuners
• 8 x CI interfaces
• 16 x QAM or COFDM full band modulators
• Electronically adjustable output level
• Suitable for adjacent channels
• Symbol rates and modulation individually adjustable
• Multiplexing & IP pool
• TV-Service Multiplexing from all inputs at each output transponder to optimize available bandwidth
• TV-Service Multiplexing at the CA-modules to reduce amount of CAM’s
• Integrated Satellite Channel Router (SCR) multiswitch*
• Reception of up to 4 satellite positions with each 2 polarizations and 2 frequency bands
• Transport Stream Processing
• Network Information Table (NIT) for complete headend station
• LCN (Logical Channel Numbering)
• SID, TSID and ONID management
• To handle conflicts during multiplexing
• To handle changes if required
• PID management
• To handle PID conflicts
• PID filtering to reduce audio channels from a TV service
• Distribute TV services multiple times with different languages In case of service changes to secure no new TV channel tune
• EPG management
• To manage the amount of EPG-data distributed in an output transponder
• To support TVs with EPG data from all TV services without the need of retuning all transponders
• Service Filtering with the option for
• Remove unwanted services
• Remove services for minimize data rate-
• Real time output load measurement
• Dashboard
• System information and overview without login
• HTML user interface via self-signed HTTPS
