TRIAX 492781 TDcH 16S-I 16xDVB-S/S2 to DVB-T or DVB-C Compact Headend with 8xCI Interfaces
Description
The Triax TDcH 16S-I (492781) COMPACT Series Professional TV Headend is a versatile platform designed for professional TV signal reception and distribution. It supports Free-to-Air (FTA) television services, Freeview via the VAST (Viewer Access Satellite Television) Remote FTA Satellite Service and FOXTEL. The unit can decrypt subscription services using CAM modules and smart cards via integrated CI slots and can simultaneously output content as DVB-T COFDM digital terrestrial signals and Multicast IPTV streams (UDP / RTP). This makes it an ideal solution for hotels, motels, aged care facilities, apartment complexes, and other multi-dwelling or commercial television distribution environments.
Available Feature License Activations
- TDcH-IPOUT 418740 Multicast IPTV OUT (Max 100 Streams)
- TDcH-IPIN04 418745 Multicast IPTV INPUT (Max 4 Streams)
- TDcH-IPIN16 418746 Multicast IPTV INPUT (Max 16 Streams)
- TDcH-IPIN96 418747 Multicast IPTV INPUT (Max 95 Streams)
- TDcH-Media/2 418780 Max 2 Channel Internal Madia Player
- TDmH-Media/4 418781 Max 4 Channel Internal Madia Player
- TDcH-SNMP 418762 SNMP Monitoring
Key Features:
- Receives Freeview VAST via satellite, FTA satellite and FOXTEL services
- CI slots for CAM and Smartcard-based service decryption
- DVB-T COFDM RF output
- Supports simultaneous Multicast IPTV output (UDP/RTP)
- Professional headend solution for MATV and SMATV networks
- Compact Series modular design
- Rack Mounting 19” 3RU or Wall Mounting Kit included
A great solution for VAST and FOXTEL offering output on DVB-T UHF or upgradeable to include Multicast IPTV UDP/RTP. Includes extra services delivered by HDMI Sources
headend. Complimentary updated software offers new and existing customers additional functions, benefits, and powerful hardware configurations to match your requirements.
Features – Triax TDcH-16S-I 492781
- 16 × DVB-S/DVB-S2 Satellite Transponder Inputs
- 8 × Common Interface (CI) Slots for CAM modules and smart cards
- 16 × DVB-T COFDM UHF Adjacent Channel Outputs
- Upgradeable License Option for simultaneous Multicast IPTV OUTPUT, supporting up to 100 SPTS (Single Program Transport Stream) UDP / RTP streams
- Upgradeable License Options for Multicast IPTV INPUT conversion to DVB-T COFDM output, supporting 4, 16 or 96 SPTS and MPTS (Multiple Program Transport Stream) UDP/RTP streams
- Upgradeable License Options to enable either a 2 Channel or 4 Channel internal Digital Signage Media Player with output to DVB-T and or 2 or 4 SPTS IPTV UDP / RTP streams
- Upgradeable License Option for SNMP network monitoring and management
- Channel Multiplexing capabilities for both RF and IP outputs
Applications
The TDcH-16S-I 492781 is ideal for:
- Hotels and resorts
- Motels and caravan parks
- Aged care facilities
- Hospitals and healthcare facilities
- Apartment buildings and MDUs
- Clubs and commercial venues
- Educational campuses
Summary
The Triax TDcH-16S-I492781 Compact Series Professional TV Headend combines satellite reception, CI-based decryption, DVB-T modulation for MATV and SMATV, IPTV streaming, and channel multiplexing scalable platform. With support for VAST Freeview satellite FTA television, and FOXTEL services, it provides a powerful solution for professional RF DVB-T MATV and Multicast IPTV distribution networks.
Power Supply & Injectors
Power Lead: 2pin AU wall plug to IEC C7 connector (Figure 8) 1.8M
$6.60 Inc. GST
Accessories
Triax 492086 SFP RJ45 Ethernet Adaptor Support 1000BASE-T Req. with TDcH & TDmH for IPTV IN/OUT
$632.50 Inc. GST
Additional information
| Weight | 6 kg |
|---|---|
| Dimensions | 51 × 28 × 15 cm |
Download
Available downloads for this item:
Click to view - TRIAX TDcH & TDmH – 5 Year Limited Warranty
Click to view - TRIAX TDcH & TDmH Headend User Manual
Click to view - TRIAX – Proud Heritage Brochure
Click DOWNLOAD LINK - TRIAX Products - Latest Firmware
